Combine harvester
DC-70 Plus KIS
DC-70 Plus เกี่ยวดี ชีวิตดี
Starting price
995,000 Baht
horsepower
69.00 horsepower
Calculate annuity
Test drive
DealerGalleryCombine harvester
Application features
ประสิทธิภาพ
-
![DC-70 Plus KIS]()
Engine
Give full capability with 70-horsepower KUBOTA diesel engine Center Direct injection type with Turbocharger for perfect combustion and high torque with stable rotation. Smooth operation with high durability
-
![DC-70 Plus KIS]()
Gain hopper
Efficient harvesting operation
-
![DC-70 Plus KIS]()
Reaper set
Add a serrated plate around the head. Helping to transport rice to the neck, conveying more continuously
-
![DC-70 Plus KIS]()
Reaper head set
Adjust the spiral angle from 90 degrees to 123 degrees for smooth transfer of the rice convoying. And reaper finger is designed to be inside to reduce problems of rice stuck in the convoyer area.
-
![DC-70 Plus KIS]()
Conveyer chain gear
Designed larger gear to decrease chain problems and gear sprocket while working
-
![DC-70 Plus KIS]()
Hydraulic System Reaper Head
Designed to have 2 m. width with adjusted up-down independently from the reaper. Comes up with coil spring fingers that increase harvesting performance
-
![DC-70 Plus KIS]()
Treshing system
Long and wide tresher with 2 layers of rice sieve with 3 levels wind blowing is available and adjustable to 4 levels of rice sieve
-
![DC-70 Plus KIS]()
ติดตั้งระบบ KIS
ระบบคูโบต้านวัตกรรมอัฉริยะ รายงานการเคลื่อนไหว แจ้งเตือนการโจรกรรม และแจ้งเตือนการบำรุงรักษาตามระยะเวลาที่เหมาะสม
Durability
-
![DC-70 Plus KIS]()
Metal sheet under the reaper
Made with high-tension steel durable up 1.4 - 2.0 times *
-
![DC-70 Plus KIS]()
More durable blade sheet
To prevent dust, soil debris, straw into the bearing
-
![DC-70 Plus KIS]()
Metal sheet under the convoyer
Made with high-tension steel durable up 1.4 - 2.0 times *
-
![DC-70 Plus KIS]()
Crawler
Width and length of 50 and 170 cm. with high tire tread of 55 mm
-
![DC-70 Plus KIS]()
Roller
Thick and width roller for better track surfaces
-
![DC-70 Plus KIS]()
Supporting steel for crawler
Curved design to support weight for crawler surfaces
-
![DC-70 Plus KIS]()
Rear bearing
Designed to be large, strong, durable for high pressure
Comfort
-
![DC-70 Plus KIS]()
Side mirror
More safety and comfortable
-
![DC-70 Plus KIS]()
Fan breaker
Comfort to use
-
![DC-70 Plus KIS]()
Electric trailer on the side of the driver
For light bulbs connection for night use
-
![DC-70 Plus KIS]()
Wide Convoyer
Easy for maintenance
-
![DC-70 Plus KIS]()
Belt
Only 12 belts ease to remove for maintenance
-
![DC-70 Plus KIS]()
Seperating sieve
Easy to remove for maintenance
-
![DC-70 Plus KIS]()
Convoyer system
Tresher convoyer and rice sieve made of stainless steel for long lasting use
Value
-
![DC-70 Plus KIS]()
คุ้มค่า รองรับน้ำมัน B20
ประหยัดต้นทุนค่าน้ำมัน 3.25 บาท/ลิตร* ลดมลพิษ เป็นมิตรต่อสิ่งแวดล้อม ลดปัญหาฝุ่นละอองขนาดเล็ก PM 2.5 และเป็นส่วนหนึ่งที่ช่วยสนับสนุนเกษตรกรสวนปาล์ม
*หมายเหตุ : เปรียบเทียบราคาน้ำมันดีเซล B20 กับดีเซล B7 วันที่ 1 ก.ค. 63
Specifications
| Engine specification | ||
|---|---|---|
| Series | KUBOTA V2403-M-DI-TE2-CSKC | |
| Type | 4-cylinders 4-strokes direct injection with water cooling system | |
| Cylinder volume | (liter {cc}) | 2.434 (2,434) |
| Maximum horsepower / maximum rev. | (hp / rpm*) | - |
| Maximum horsepower (HP) / rev. | (hp / rpm*) | - |
| Maximum horsepower (PS) / rev. | (hp / rpm*) | - |
| Net horsepower (HP) / rev. | (hp / rpm*) | - |
| Net horsepower (PS) / rev. | (hp / rpm*) | 69/2,700 |
| Fuel type | Diesel | |
| Fuel capacity | (liters) | 85 |
| Starting system | Starter motor | |
| Battery | (volts / ampere-hours) | 12/52 |
| Specifications | ||
|---|---|---|
| Type | 4-cylinders 4-strokes direct injection with water cooling system | |
| Weight | 3,000 | |
| Car body size | ||
| Total length | (millimeter) | 4,800 |
| Total width | (millimeter) | 2,260 |
| Total height | (millimeter) | 2,880 |
| Drive part | ||
| Height under the car | (millimeter) | 325 |
| How to change speed | Hydraulic transmission (HST) | |
| Turning pattern | Electronically controlled turn brakes | |
| Reaper header | ||
| Rice extraction system | Reel set | |
| Width of the tusk [head tusk] | (millimeter) | 2,075 |
| Diameter x Length | ((mm) x Number of fingers pulling rice (pieces)) | 900x5 |
| Blade width | (millimeter) | 1,980 |
| Massage part | ||
| Massage system | Shaft Flowing system (treshing tooth) | |
| Grain conveying system | Auger screw system | |
| Sorting method | gliding/use of wind (Separation using 3-way airflow) | |
| Grain drainage type | ||
| Storage tank Grain hopper capacity | (kilograms) | 300 |
| Rain container Grain hopper capacity | (kilograms (liters)) | - |
| Storage tank | 2/packed into bags | |
| Grain container | - | |
| Warning device | Water temperrature of radiator, electric charging, pressure of engine oil, fulness of rice container blockage of transferring screw | |
| Harvesting ability to fall | (degrees) | 85 or less by harvesting along the falling direction, 70 or less by harvesting against the falling direction |
